Quickstart

This guide walks through downloading an OS image, creating a virtual machine, connecting to it, and managing its lifecycle in BarkVisor.

Prerequisites

• BarkVisor is installed and the daemon is running:
  • macOS: sudo launchctl list | grep barkvisor
  • Linux: systemctl status barkvisor.service (or swift run BarkVisorApp in dev)
• The server is listening on port 7777 (default).
• At least one OS image is available, or you are ready to download/upload one.
• QEMU is available:
  • macOS release: bundled under /usr/local/libexec/barkvisor/
  • macOS dev: brew install qemu (Homebrew / $PATH)
  • Linux: distro packages via ./scripts/linux-dev.sh or package Recommends (see Linux guide)

Getting an OS Image

BarkVisor supports two image types:

Type	Use case
iso	Installer ISO (manual OS install via VNC)
cloud-image	Pre-built cloud image (automated via cloud-init)

Architecture follows the host: arm64 on Apple Silicon and Linux aarch64; x86_64 on Linux amd64 hosts. Pick catalog images and vmType (linux-arm64 / linux-amd64) that match GET /api/system/capabilities (hostArch).

Downloading from a Repository

1. Open the BarkVisor web UI at http://localhost:7777.
2. Navigate to Images (or Registry if browsing repository catalogs).
3. Browse the available repository images and click Download.
4. BarkVisor streams the file from the source URL with a progress indicator (SSE-based). If the download fails, it retries automatically up to 4 attempts with exponential backoff (2 s, 4 s, 8 s).
5. Files ending in .xz or .gz are decompressed automatically after download using xz or gunzip.

Uploading an Image (TUS Resumable Upload)

BarkVisor implements the TUS 1.0.0 resumable upload protocol. The frontend uses tus-js-client to upload images in 50 MB chunks.

1. Go to Images and click Upload.
2. Select a local ISO or cloud image file.
3. Provide a name, image type (iso or cloud-image), and arch (arm64 or x86_64).
4. The upload streams to the server in chunks. If the connection drops, resume from where it left off — the server tracks the byte offset.
5. When the upload completes, the image status transitions to ready.

The maximum upload size is 128 GB (Tus-Max-Size: 137438953472).

Creating a VM from the Wizard

Click Create VM to open the creation wizard. It walks through the following steps:

Step 1: OS Type and Name

• Choose Linux or Windows. On Apple Silicon this typically sets vmType to linux-arm64 or windows-arm64. On Linux x86_64 hosts use linux-amd64 (and matching catalog images); the wizard follows host capabilities from GET /api/system/capabilities.
• Enter a VM name (1—128 characters).
• Windows selection automatically adjusts defaults: 4 CPUs, 4096 MB RAM, 64 GB disk, UEFI on, TPM enabled. It also ensures the VirtIO Windows drivers ISO is available (downloading it if needed).

Step 2: Hardware Configuration

Setting	Range / Options	Default (Linux)	Default (Windows)
CPU count	1—256	2	4
Memory (MB)	128—1,048,576	1024	4096
Display resolution	e.g. 1280x800, 1920x1080	1280x800	1280x800
UEFI boot	on / off	on	on
TPM	on / off (auto-enabled for Windows)	off	on

Step 3: Image Selection

Choose the boot source:

• ISO mode — Select an installer ISO. A blank boot disk is created for you. The VM boots from the ISO for a manual install.
• Cloud image mode — Select a cloud image. BarkVisor clones the image into a new qcow2 boot disk (resized to your chosen disk size). You can optionally configure cloud-init (see below).

Step 3a: Windows Drivers (Conditional)

If Windows is selected and the VirtIO Windows drivers ISO (virtio-win.iso) is not already downloaded, the wizard prompts you to download it. This ISO is automatically attached as a secondary drive during VM creation.

Step 4: Storage

• New disk — Specify the disk size in GB (minimum 1 GB, up to 8,192 GB). In ISO mode a blank qcow2 disk is created instantly. In cloud-image mode the disk is cloned and resized in a background task.
• Existing disk — Attach an unassigned disk that was previously created.
• Shared folders — Optionally share host directories with the guest via virtio-9p.

Step 5: Networking

• Select an existing network (NAT, bridged, or socket_vmnet). The default network is pre-selected.

• Port forwarding (NAT only) — Add TCP/UDP rules mapping a host port to a guest port. This is how you reach SSH or other services from the host.

  Example: TCP 2222 -> 22 forwards host port 2222 to guest port 22.

Step 6: Cloud-Init (Cloud Image Mode Only)

When using a cloud image, you can provide:

• SSH public key — Select from your stored SSH keys (the default key is pre-selected). The key is injected via cloud-init ssh_authorized_keys.
• User data — A free-form cloud-init user data script (YAML). Validated before submission.

Step 7: Review and Create

The summary shows all chosen settings and a preview of the equivalent QEMU command line. Click Create to provision the VM.

• ISO mode: The VM is created synchronously (status: stopped).
• Cloud image mode: The VM enters provisioning state while a background task clones the disk and generates the cloud-init ISO. The API returns HTTP 202 with a taskID you can poll. Once provisioning completes the VM transitions to stopped.

Creating a VM from a Template

Templates are pre-configured VM recipes that include an OS image slug, hardware defaults, port forwards, and a cloud-init user data template with fill-in-the-blank inputs.

1. Navigate to Templates in the web UI.
2. Browse templates by category and select one.
3. Fill in the required inputs (e.g. hostname, password, SSH key). The template defines which inputs are required, their min/max length, and default values.
4. Optionally override CPU, memory, disk size, or network.
5. Click Deploy.

If the template’s image is not yet downloaded locally, BarkVisor automatically starts the download and returns a "downloading" status. Monitor the image download progress on the Images page; once the image is ready, deploy again.

If the image is already available, the VM is created immediately through the same pipeline as the wizard (cloud-image mode with rendered user data).

Starting a VM and Connecting

Start

Select the VM and click Start. BarkVisor launches a qemu-system-aarch64 process with HVF acceleration, UEFI firmware, and all configured devices. The VM state transitions to running.

VNC (Graphical Console)

Click the VNC tab on the VM detail page. BarkVisor embeds a NoVNC client that connects over a WebSocket to the QEMU VNC socket (proxied through the server at /api/vms/:id/vnc). This gives you a full graphical console in the browser — useful for OS installation and desktop environments.

Serial Console

Click the Console tab. BarkVisor embeds an xterm.js terminal that connects over a WebSocket to the QEMU serial socket at /api/vms/:id/console. This is the primary interface for headless Linux servers.

SSH via Port Forwarding

If you configured a port forward (e.g. TCP 2222 -> 22), connect from your host terminal:

ssh -p 2222 user@localhost

The guest’s default IP on a NAT network is 10.0.2.15. Port forwarding is configured through QEMU’s user-mode networking (-netdev user,hostfwd=...).

Stopping and Managing VMs

Stop Methods

BarkVisor supports three stop methods, selectable from the stop button dropdown:

Method	Behavior
guest-agent	Sends a shutdown command via qemu-guest-agent (graceful).
acpi	Sends an ACPI power button event (like pressing the button).
force	Immediately terminates the QEMU process (like pulling power).

The default is guest-agent. If the guest agent is not installed, fall back to acpi or force.

Restart

Restart sends a stop followed by a start. The VM must be running.

Disk Hotplug

You can attach and detach additional disks to a running VM without rebooting:

• Hot-add: On the VM detail page, click Attach Disk, select an unassigned disk, and confirm. The disk is added via QMP blockdev-add + device_add.
• Hot-remove: Click the eject icon on an additional disk. The disk is removed via QMP device_del + blockdev-del.

The boot disk cannot be hot-removed.

Online Disk Resize

Disks can be resized (grow only) from the Disks page via the resize action. The new size must be at least 1 GB and at most 8,192 GB. After resizing on the host, the guest OS must expand its filesystem to use the new space (e.g. growpart + resize2fs on Linux).

ISO Attach/Detach

You can attach or detach ISO images on a running VM:

• Attach ISO: Adds a virtual CD-ROM drive.
• Detach ISO: Removes a specific ISO or all ISOs.

Monitoring

Live Metrics

The Metrics tab on the VM detail page shows real-time charts powered by Chart.js:

• CPU utilization (percent)
• Memory usage (MB)
• Disk I/O (read/write bytes per interval)

Metrics are collected every 5 seconds via QMP queries to the running QEMU process and stored in a 30-minute ring buffer (360 samples). The metrics stream is delivered to the browser via Server-Sent Events (SSE) at /api/vms/:id/state.

Guest Information (qemu-guest-agent)

If qemu-guest-agent is installed in the guest, the Overview tab displays rich guest info polled by the MetricsCollector:

• IP addresses (source: guest-agent; falls back to 10.0.2.15 for NAT)
• Hostname
• OS name, version, and ID
• Kernel version and release
• Architecture
• Timezone
• Logged-in users
• Filesystem mount points and usage

Guest info is available at GET /api/vms/:id/guest-info and is persisted to the database for offline reference.
